| Genset Model | CU42GFS | ||||
| Prime Power(KW/KVA) | 30/37.5 | ||||
| Standby Power(KW/KVA) | 33/42 | ||||
| Overall Size(mm) | Length(mm) | 2500 | |||
| Width(mm) | 1050 | ||||
| Height(mm) | 1250 | ||||
| Gross Weight(kg) | 1095 | ||||
| Diesel Engine | |||||
| Brand | Cummins | ||||
| Model | 4BT3.9-G2 | ||||
| Type | Closed water-cooled,4-stroke,wet cylinder liner,direct injection,1500rpm | ||||
| Rated Power(KW) | 36 | ||||
| Intake Type | Turbocharged | ||||
| No.of Cylinder | 4. L | ||||
| Bore x Stroke(mm) | 102x120 | ||||
| Compression ratio | 18:1 | ||||
| Displacement(L) | 3.9L | ||||
| Mechanical Governor Rate | ≦5% | ||||
| Electronic Governor Rate | ≦1% | ||||
| Lub oil Capacity(L) | 11 | ||||
| Rated Fuel Consumption(L/h) | 10(100% load) | ||||
| Starting method | 24V DC Electric Starting | ||||
| Governing Type | Electrical governor | ||||
| Alternator | |||||
| Model | BC184H | ||||
| Brand | Supermaly | ||||
| Rated Power(KW) | 30 | ||||
| Power Efficiency | 86.70% | ||||
| Voltage Regulation | automatic | ||||
| Excitation Type | Brushless | ||||
| Insulation Class | H | ||||
| Controller system | |||||
| Model | Deepsea DSE6120 | ||||
| Protection | Under/Over Voltage, Over Load & Short Ckt. | ||||
| Protections for Engines | Over Speed, Under Speed, Low Oil Pressure, Over Heat, Low Coolant Level, Over Crank, Low Fuel, Auxiliary Fault | ||||
| Starting system | Auto Starting System with Manual Key | ||||
| fuel tank | standard base fuel tank for 8hrs capacity | ||||
