| CUMMINS 200KVA DIESEL GENERATOR SPECIFICATION | |||
| Voltage:230/400/1500r/m | |||
| Frequency:50Hz | |||
| Power factor:0.8 | |||
| Phase:3Ph | |||
| Protection degree: IP23 | |||
| Insulation Class: H | |||
| Efficiency more than: 85% | |||
| Generator passed CE certificate | |||
| Generator passed ISO certificate | |||
| warranty:one year or 1000running hrs whichever comes first. | |||
| Genset Model | Silent Type | CU200GFS | |
| Standby Power (KW/KVA) | 160/200 | ||
| Prime Power(KW/kVA) | 150/188 | ||
| CUMMINS Diesel Engine | Model | 6CTA8.3-G2 | |
| Type | water-cooled, in line, 4-stroke, direct injection | ||
| Standby Power(kW) | 180 | ||
| Aspiration | Turbocharged and aftercooled | ||
| No.of Cylinder | 6 | ||
| Bore x Stroke(mm) | 114x135 | ||
| Displacement | 8.3 | ||
| Compression Ratio | 17.3:1 | ||
| Noise Level (dBA) | 75 | ||
| Electronic Governor Rate | ≦1% | ||
| Exhaust Temperature(°C) | 563 | ||
| Lub oil Capacity(L) | 27.6 | ||
| Rated Fuel Consumption75% (L/h) | 31 | ||
| STAMFORD technology Alternator | Model | UC274G | |
| Standby Power(kW/kVA) | 160/200 | ||
| Voltage Regulation | ≦±1 | ||
| Excitation Type | Brushless | ||
| Controller | Deepsea brand | DSE6120 | |
| Fuel tank | sub-base | 8hrs working capacity | |
| Overall Size(mm) | Length | 3150 | |
| Width | 1120 | ||
| Height | 1500 | ||
| Gross Weight(kg) | 2100 | ||
| With ,battery, battery charger,shock absorber , cummins manual book etc. | |||
